Foundation measurement The level of rigidity and the transmission characteristics of foundations, hall floors or ceilings can be measured using special low-frequency measuring displacement or velocity sensors. Then the excitation of the corresponding building structures is measured using a heavy impact hammer.

Cutting simulation An accurate representation of the surface texture and characteristic values after machining can be achieved using standard models for milling, turning or grinding and individual models of special processes. The individual forces and displacements can also be established in this way.

HS-spindle concentricity The measurement of the dynamic spindle concentricity is preferably carried out without contact by means of eddy current sensors measuring in several directions simultaneously. Both the axialdisplacement of the spindle and the resonance regions of the spindle bearing system can be detected.

planlauf/SPINDLE planlauf/SPINDLE is our software for the simulation of the static and dynamicnproperties of main spindles based on the Finite Element Method. We placed particular emphasis on intuitive operation and short computation times when developing this software.

Measurement software To increase measurement accuracy, reliability and speed we develop appropriate algorithms to monitor and evaluate your specific measurement scenarios software solutions which meet your needs regarding measured variables, file formats and compatibility with instruments.

Cutting force Force-measuring platforms under the workpiece or integrated force sensors measure high dynamic cutting forces in the coordinate three directions. Subsequently, the process can be optimized by reducing peak loads, thereby increasing the life of tools.

Displacement measurement The displacement of machine components under the weight of workpieces or due to the loads in processes, the overshoot and the repeatability of dynamic positioning of the axes can be monitored relative to the machine or relative to the floor of the hall. This monitoring can be carried out both in the short-term […]

Measuring electronics We construct robust and easy-to-use measurement electronics for safe use in industrial environments. High quality sensors and electronics, with which we have had good experience, are selected for your specific applications.

Temperature measurement Precise measuring of temperatures, while a machine is in use, are carried out over an appropriate period of time to determine the accuracy of the machine. This is done using thermocouples in all major components of the machine. Possible impacts can thus be assessed directly in combination with displacement measurements.
